+2.7V, Low-Power, Multichannel,

Serial 8-Bit ADCs

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional

operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to

absolute maximum rating conditions for extended periods may affect device reliability.

VDD to AGND ..............................................................-0.3V to 6V

AGND to DGND .......................................................-0.3V to 0.3V

CH0–CH7, COM, REFIN,

REFOUT to AGND ......................................-0.3V to (VDD + 0.3V)

Digital Inputs to DGND ...............................................-0.3V to 6V

Digital Outputs to DGND ............................-0.3V to (VDD + 0.3V)

Continuous Power Dissipation (TA = +70°C)

16 Plastic DIP (derate 10.53mW/°C above +70°C) ......842mW

16 QSOP (derate 8.30mW/°C above +70°C) ................667mW

16 CERDIP (derate 10.00mW/°C above +70°C) ..........800mW

20 Plastic DIP (derate 11.11mW/°C above +70°C) ......889mW

20 SSOP (derate 8.00mW/°C above +70°C) ................640mW

20 CERDIP (derate 11.11mW/°C above +70°C) ..........889mW

Operating Temperature Ranges

MAX1110C_P/MAX1111C_E................................0°C to +70°C

MAX1110E_P/MAX1111E_E .............................-40°C to +85°C

MAX1110MJP/MAX1111MJE..........................-55°C to +125°C

Storage Temperature Range .............................-65°C to +150°C

Lead Temperature (soldering, 10sec) .............................+300°C

ELECTRICAL CHARACTERISTICS

(VDD = +2.7V to +5.5V; unipolar input mode; COM = 0V; fSCLK = 500kHz, external clock (50% duty cycle); 10 clocks/conversion

cycle (50ksps); 1µF capacitor at REFOUT; TA = TMIN to TMAX; unless otherwise noted.)

-3dB rolloff

MHz

1.5

Small-Signal Bandwidth

kHz

800

VCH_ = 2.048Vp-p, 25kHz (Note 4)

External reference, 2.048V

VDD = 2.7V to 3.6V

No missing codes over temperature

±0.35

±1

CONDITIONS

Full-Power Bandwidth

±1

Internal or external reference

LSB

Gain Error (Note 3)

-75

Channel-to-Channel Crosstalk

SFDR

Spurious-Free Dynamic Range

-70

THD

Total Harmonic Distortion

(up to the 5th harmonic)

±0.15

±0.5

LSB

±0.1

Channel-to-Channel

Offset Matching

ppm/°C

±0.8

Gain Temperature Coefficient

LSB

±1

DNL

Differential Nonlinearity

UNITS

MIN

TYP

MAX

SYMBOL

PARAMETER

LSB

±0.3

±1

TUE

Total Unadjusted Error

Bits

Resolution

SINAD

Signal-to-Noise

and Distortion Ratio

VDD = 5.5V (Note 2)

LSB

±0.2

INL

Relative Accuracy (Note 1)

VDD = 5.5V (Note 2)

LSB

±0.5

Offset Error

DC ACCURACY

DYNAMIC SPECIFICATIONS (10.034kHz sine-wave input, 2.048Vp-p, 50ksps, 500kHz external clock)
