AS7150

Datasheet • PUBLIC • Document Feedback

DS001130 • v3-00 • 2026-Jan-26

89 / 159

8.7.2

SEQ1_SUB12_PP register (Address 0x38)

Table 52: SEQ1_SUB12_PP register

Addr: 0x38

SEQ1_SUB12_PP

Bit

Bit name

Default

Access

Bit description

7:6

mod1_seq1_sub1_pp

R/W

This register configures the post processing

function for ADC modulator channel 1 for

subsample 1 in sequencer 1.

0: Normal value

1: Inverted value

2: Value – pp_offset register value

3: Write value to pp_offset register

5:4

mod2_seq1_sub1_pp

R/W

This register configures the post processing

function for ADC modulator channel 2 for

subsample 1 in sequencer 1.

0: Normal value

1: Inverted value

2: Value – pp_offset register value

3: Write value to pp_offset register

3:2

mod1_seq1_sub2_pp

R/W

This register configures the post processing

function for ADC modulator channel 1 for

subsample 2 in sequencer 1.

0: Normal value

1: Inverted value

2: Value – pp_offset register value

3: Write value to pp_offset register

1:0

mod2_seq1_sub2_pp

R/W

This register configures the post processing

function for ADC modulator channel 2 for

subsample 2 in sequencer 1.

0: Normal value

1: Inverted value

2: Value – pp_offset register value

3: Write value to pp_offset register
