Rev 1.3

8.5.4. Interrupts

TWI master controller interrupts are generated on the following events:



Bus command (SC_TWISTART/SC_TWISTOP) completed (0 to 1 transition of SC_TWICMDFIN)



Character transmitted and slave device responded with NACK



Character transmitted (0 to 1 transition of SC_TWITXFIN)



Character received (0 to 1 transition of SC_TWIRXFIN)



Received and lost character while receive FIFO was full (receive overrun error)



Transmitted character while transmit FIFO was empty (transmit underrun error)

To enable CPU interrupts, set the desired interrupt bits in the second-level INT_SCxCFG register, and enable the

top-level SCx interrupt in the NVIC by writing the INT_SCx bit in the INT_CFGSET register.

8.5.5. Registers

Refer to "8.3.5. Registers" on page 79 (in “8.3. SPI—Master Mode” ) for a description of the SCx_DATA,

SCx_RATELIN, and SCx_RATEEXP registers.

Note:

Substitute “1” or “2” for “x” in the following detailed descriptions.

SC1_TWISTAT: Address: 0x4000C844 Reset: 0x0



SC2_TWISTAT: Address: 0x4000C044 Reset: 0x0



SC1_TWISTAT: TWI Status Register



SC2_TWISTAT: TWI Status Register

Bit

Name

Bit

Name

Bit

Name

Bit

Name

SC_TWICMDFIN SC_TWIRXFIN SC_TWITXFIN SC_TWIRXNAK

Bitname

Bitfield

Access

Description

SC_TWICMDFIN

[3]

This bit is set when a START or STOP command completes. It clears on the next TWI

bus activity.

SC_TWIRXFIN

[2]

This bit is set when a byte is received. It clears on the next TWI bus activity.

SC_TWITXFIN

[1]

This bit is set when a byte is transmitted. It clears on the next TWI bus activity.

SC_TWIRXNAK

[0]

This bit is set when a NACK is received from the slave. It clears on the next TWI bus

activity.
