background image
Rev 1.3
60
GPIO_PAIN: Address: 0x4000B008 Reset: 0x0
GPIO_PBIN: Address: 0x4000B408 Reset: 0x0
GPIO_PCIN: Address: 0x4000B808 Reset: 0x0
Register 7.3. GPIO_PxIN
GPIO_PAIN: Port A Input Data Register
GPIO_PBIN: Port B Input Data Register
GPIO_PCIN: Port C Input Data Register
Bit
31
30
29
28
27
26
25
24
Name
0
0
0
0
0
0
0
0
Bit
23
22
21
20
19
18
17
16
Name
0
0
0
0
0
0
0
0
Bit
15
14
13
12
11
10
9
8
Name
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
Name
Px7
Px6
Px5
Px4
Px3
Px2
Px1
Px0
Bitname
Bitfield
Access
Description
Px7
[7]
RW
Input level at pin Px7.
Px6
[6]
RW
Input level at pin Px6.
Px5
[5]
RW
Input level at pin Px5.
Px4
[4]
RW
Input level at pin Px4.
Px3
[3]
RW
Input level at pin Px3.
Px2
[2]
RW
Input level at pin Px2.
Px1
[1]
RW
Input level at pin Px1.
Px0
[0]
RW
Input level at pin Px0.
