background image
TSSOP8 (DW)
169 mil width
SO8N (MN)
150 mil width
UFDFPN8 (MC)
DFN8 - 2x3 mm
WLSCP (CU)
WLSCP (CS)
Unsawn wafer
Features
•
Compatible with following I2C bus modes:
–
1 MHz
–
400 kHz
–
100 kHz
•
Memory array:
–
512 Kbit (64 Kbyte) of EEPROM
–
Page size: 128 byte
–
Additional write lockable page (M24512-D order codes)
•
Single supply voltage and high speed:
–
1 MHz clock from 1.7 V to 5.5 V
•
Write time:
–
Byte write within 5 ms
–
Page write within 5 ms
•
Operating temperature range:
–
-40 °C up to +85 °C
•
Random and sequential read modes
•
Write protect of the whole memory array
•
Enhanced ESD/latch-Up protection
•
More than 4 million write cycles
•
More than 200-years data retention
•
Packages:
–
SO8 ECOPACK2®
–
TSSOP8 ECOPACK2®
–
UFDFPN8 ECOPACK2®
–
WLCSP ECOPACK2®
–
Unsawn wafer (each die is tested)
Product status link
M24512-W
M24512-R
M24512-DF
512-Kbit serial I²C bus EEPROM
M24512-W M24512-R M24512-DF
Datasheet
DS6520 - Rev 31 - October 2020
For further information contact your local STMicroelectronics sales office.
www.st.com
