55 / 218 page  Table 5-5. Connectivity between ADC Inputs to CMPSS Signals (continued) Signal/Pin Name ADC Input CMPSS Input ADC2_AIN0 ADC2:inp0 (+IN0) CMPSSA4:inH (+IN) ADC2_AIN1 ADC2:inm0 (-IN0) CMPSSA4:inL (-IN) ADC2_AIN2 ADC2:inp1 (+IN1) CMPSSA5:inH (+IN) ADC2_AIN3 ADC2:inm1 (-IN1) CMPSSA5:inL (-IN) ADC2_AIN4 ADC2:inp2 (+IN2) CMPSSA6:inH (+IN) ADC2_AIN5 ADC2:inm2 (-IN2) CMPSSA6:inL (-IN) ADC2_AIN6 ADC2:inm3 (-IN3) X ADC_CAL0 ADC2:inp3 (+IN3) X Note In the ADC Input column in ADC-CMPSS Signal Connectivity Table above, "inp" stands for positive inputs and "inm" stands for negative inputs. www.ti.com AM2612, AM2611, AM2611-Q1, AM2612-Q1 SPRSPA7C – SEPTEMBER 2024 – REVISED JULY 2025 Copyright © 2025 Texas Instruments Incorporated Submit Document Feedback 55 Product Folder Links: AM2612 AM2611 AM2611-Q1 AM2612-Q1 |
|
