50-604 Kotron Model 804 Sentinel II RF Level Transmitter

3.3

Specifications

3.3.1 Electrical

Power supply

120 VAC, 50/60 Hz (+10%, -15%)

240 VAC, 50/60 Hz (+10%, -15%)

24 VDC, (±10%)

Power consumption

15 VA nominal

Supply voltage effect

Less than 1 pF over full range

Ambient temperature range

-40° to +160° F (-40° to +71° C)

Humidity

99% non-condensing (electronics)

Accuracy

Better than ±1.0%

Repeatability

±0.1%

Linearity

±0.5%

Temperature effect

±0.01%/° F ±0.018%/° C)

Operator interface

Data entry

16-button keypad

Display

2-line

× 16-character LCD display

Continuous output

Signal

Active

4–20 mA (isolated reversible max. 1000 ohms loop resistance)

Passive

4–20 mA (isolated reversible max. 1000 ohms loop resistance)

Dependent on power supply)

Range

5 pF minimum; 50,000 pF maximum

Damping

0–90 seconds

Discrete output

Set point range

0–50,000 pF

Adjustable differential range

0.5 pF minimum

50,000 pF maximum

Time delay

0–90 seconds level rising, level falling, both

Relay output

10 amp @ 120/240 VAC resistive

10 amp @ 30 VDC resistive

0.5 amp @ 125 VDC resistive

Maximum remote cable length

Standard: 2500 feet (762 m)

Intrinsically safe: 800 feet (240 m)
