background image
 2016 Microchip Technology Inc.
DS20005543B-page 7
PL138-48
—
6
CLK-IN1
I
True part of differential clock input signal. 75 kΩ internal
pull-down resistor.
—
7
CLK-IN1B
I
Complementary part of differential clock input signal.
100 kΩ internal pull-up and pull-down resistors.
1, 5
8, 9
DNC
—
Do Not Connect.
8, 13
10, 13, 18
VCC
P
Power supply pin connection.
6, 9, 11 ,14
11, 14, 16, 19
QB0 ~ QB3
O
LVPECL Complementary output.
7, 10, 12, 15
12, 15, 17, 20
Q0 ~ Q3
O
LVPECL True output.
TABLE 2-1:
PIN FUNCTION TABLE (CONTINUED)
Pin Number
QFN-16
Pin Number
TSSOP-20
Pin Name
Type
Description
