PART NUMBER

MARKING

CODE

ZENER VOLTAGE

TEST

CURRENT

REVERSE

VOLTAGE

DYNAMIC

RESISTANCE

TEMPERATURE

COEFFICIENT OF

ZENER VOLTAGE



V

mA

V

nA



MIN.

NOM.

MAX.

MAX.

MAX.

MAX.

MIN.

MAX.

AZ23B2V7-V-G

D41

2.65

2.7

2.75

5

1

-

-

75 (< 83)

< 500

- 9

- 4

AZ23B3V0-V-G

D42

2.94

3.0

3.06

5

1

-

-

80 (< 95)

< 500

- 9

- 3

AZ23B3V3-V-G

D43

3.23

3.3

3.37

5

1

-

-

80 (< 95)

< 500

- 8

- 3

AZ23B3V6-V-G

D44

3.53

3.6

3.67

5

1

-

-

80 (< 95)

< 500

- 8

- 3

AZ23B3V9-V-G

D45

3.82

3.9

3.98

5

1

-

-

80 (< 95)

< 500

- 7

- 3

AZ23B4V3-V-G

D46

4.21

4.3

4.39

5

1

-

-

80 (< 95)

< 500

- 6

- 1

AZ23B4V7-V-G

D47

4.61

4.7

4.79

5

1

-

-

70 (< 78)

< 500

- 5

2

AZ23B5V1-V-G

D48

5

5.1

5.2

5

1

> 0.8

100

30 (< 60)

< 480

- 3

4

AZ23B5V6-V-G

D49

5.49

5.6

5.71

5

1

> 1

100

10 (< 40)

< 400

- 2

6

AZ23B6V2-V-G

D50

6.08

6.2

6.32

5

1

> 2

100

4.8 (< 10)

< 200

- 1

7

AZ23B6V8-V-G

D51

6.66

6.8

6.94

5

1

> 3

100

4.5 (< 8)

< 150

2

7

AZ23B7V5-V-G

D52

7.35

7.5

7.65

5

1

> 5

100

4 (< 7)

< 50

- 3

7

AZ23B8V2-V-G

D53

8.04

8.2

8.36

5

1

> 6

100

4.5 (< 7)

< 50

4

7

AZ23B9V1-V-G

D54

8.92

9.1

9.28

5

1

> 7

100

4.8 (< 10)

< 50

5

8

AZ23B10-V-G

D55

9.8

10

10.2

5

1

> 7.5

100

5.2 (< 15)

< 70

5

8

AZ23B11-V-G

D56

10.8

11

11.2

5

1

> 8.5

100

6 (< 20)

< 70

5

9

AZ23B12-V-G

D57

11.8

12

12.2

5

1

> 9

100

7 (< 20)

< 90

6

9

AZ23B13-V-G

D58

12.7

13

13.3

5

1

> 10

100

9 (< 25)

< 110

7

9

AZ23B15-V-G

D59

14.7

15

15.3

5

1

> 11

100

11 (< 30)

< 110

7

9

AZ23B16-V-G

D60

15.7

16

16.3

5

1

> 12

100

13 (< 40)

< 170

8

0.5

AZ23B18-V-G

D61

17.6

18

18.4

5

1

> 14

100

18 (< 50)

< 170

8

0.5

AZ23B20-V-G

D62

19.6

20

20.4

5

1

> 15

100

20 (< 50)

< 220

8

10

AZ23B22-V-G

D63

21.6

22

22.4

5

1

> 17

100

25 (< 55)

< 220

8

10

AZ23B24-V-G

D64

23.5

24

24.5

5

1

> 18

100

28 (< 80)

< 220

8

10

AZ23B27-V-G

D65

26.5

27

27.5

5

1

> 20

100

30 (< 80)

< 250

8

10

AZ23B30-V-G

D66

29.4

30

30.6

5

1

> 22.5

100

35 (< 80)

< 250

8

10

AZ23B33-V-G

D67

32.3

33

33.7

5

1

> 25

100

40 (< 80)

< 250

8

10

AZ23B36-V-G

D68

35.3

36

36.7

5

1

> 27

100

40 (< 90)

< 250

8

10

AZ23B39-V-G

D69

38.2

39

39.8

5

1

> 29

100

50 (< 90)

< 300

10

12

AZ23B43-V-G

D70

42.1

43

43.9

5

1

> 32

100

60 (< 100)

< 700

10

12

AZ23B47-V-G

D71

46.1

47

47.9

5

1

> 35

100

70 (< 100)

< 750

10

12

AZ23B51-V-G

D72

50

51

52

5

1

> 38

100

70 (< 100)

< 750

10

12
