background image
INTEGRATED
API4000M SERIES
CIRCUITS INC.
VOICE OTP MODULE
Ver1.1
2
ABSOLUTE MAXIMUM RATING
Supply Voltage ( VDD to GND )
------------------
5V
Input Voltage Range
------------------
(GND- 0.3V) to (VDD + 0.3V)
Operating Temperature Range
------------------
0℃ to +60℃
ELECTRICAL CHARACTERISTICS
( VDD=4.5V , GND=0V ,Ta=+25℃ , unless otherwise noted )
PARAMETER
CONDITIONS
MIN
TYP
MAX UNITS
Standby Current
Chip Shut Down
10
uA
Operating Current
Sound On 8 ohm Speaker
50
mA
Input low voltage
Input Pins exclude AmpIn
0.8
V
Input high voltage
Input Pins exclude AmpIn
3.2
V
output low voltage
Iout = -0.1mA for Output Pins
0.5
V
output high voltage
Iout = 0.1mA for Output Pins
3.8
V
PIN DESCRIPTION
NO
Pin Name
Description
1
VDDD
Digital Positive Power Supply
2
VDDA
Analog Positive Power Supply
3
GNDD
Digital Negative Power Supply
4
GNDA
Analog Negative Power Supply
5
AMPOUT
Power Amplifier Output
6
AMPIN
Power Amplifier Input
7
OSC1
Oscillator Input
8
OSC2
Oscillator Output
9
PI3
Data Input Pin
10
PI2 ~ PI0
Data Input/Output Pins
11
PIO3 ~ PIO0
Data Input/Output Pins
12
PO3 ~ PO0
Data Output Pins
13
CEN
Memory Chip Enable Pin , Low Active
14
OEN
Memory Data Out Enable Pin , Low Active
15
D7 ~ D0
Memory Data Input Pins
16
A23 ~ A0
Memory Address Output Pins
