6.11.5.9 Local Interconnect Network (LIN)

Note

The device has multiple LIN modules. LINn is a generic prefix applied to LIN signal names, where n

represents the specific LIN module.

For more information, see the Local Interconnect Network (LIN) Module section in the device TRM.

6.11.5.9.1 LIN Timing Conditions

PARAMETER

MIN

MAX

UNIT

INPUT CONDITIONS

SRI

Input Slew Rate

V/ns

OUTPUT CONDITIONS

Output Load Capacitance

6.11.5.9.2 LIN Timing Requirements

NO.

PARAMETER

DESCRIPTION

MIN

MAX

UNIT

LIN2

td(LINn_RX)

Delay time, LINn_RX shift register to

LINn_RX pin

6.11.5.9.3 LIN Switching Characteristics

NO.

PARAMETER

DESCRIPTION

MIN

MAX

UNIT

LIN4

td(LINn_TX)

Delay time, LINn_TX shift register to LINn_TX pin
