ISCN232D datasheet(2/2 Pages) ISC

2 / 2 page

isc website：www.iscsemi.com

isc & iscsemi is registered trademark

isc Silicon NPN Power Transistor

ISCN232D

ELECTRICAL CHARACTERISTICS

TC=25℃ unless otherwise specified

SYMBOL

PARAMETER

CONDITIONS

MIN

TYP.

MAX

UNIT

V(BR)CBO

Collector-Base Breakdown Voltage

IC= 0.1mA; IE= 0

800

V(BR)CEO

Collector-Emitter Breakdown Voltage

IC= 1mA; IB= 0

450

V(BR)EBO

Emitter-Base Breakdown Voltage

IE= 0.1mA; IC= 0

VCE(sat)

Collector-Emitter Saturation Voltage

IC= 2A; IB= 0.5A

1.0

VBE(sat)

Base-Emitter Saturation Voltage

IC= 2A; IB= 0.5A

1.4

ICBO

Collector Cutoff Current

VCB= 800V; IE= 0

0.1

IEBO

Emitter Cutoff Current

VEB= 9V; IC= 0

0.1

hFE

DC Current Gain

IC= 1A ; VCE= 5V
