T89C51RB2/RC2

Mnemonic

Pin Number

Type

Name and Function

DIL

LCC

VQFP44

1.4

P2.0-P2.7

21-28

24-31

18-25

I/O

Port 2: Port 2 is an 8-bit bidirectional I/O port with internal pull-ups.

Port 2 pins that have 1s written to them are pulled high by the internal

pull-ups and can be used as inputs. As inputs, Port 2 pins that are

externally pulled low will source current because of the internal pull-

ups. Port 2 emits the high-order address byte during fetches from external

program memory and during accesses to external data memory that use

16-bit addresses (MOVX @DPTR).In this application, it uses strong

internal pull-ups emitting 1s. During accesses to external data memory

that use 8-bit addresses (MOVX @Ri), port 2 emits the contents of the

P2 SFR. Some Port 2 pins receive the high order address bits during

EPROM programming and verification:

P2.0 to P2.5 for 16Kb devices

P2.0 to P2.6 for 32Kb devices

P3.0-P3.7

10-17

11,

13-19

5,

7-13

I/O

Port 3: Port 3 is an 8-bit bidirectional I/O port with internal pull-ups.

Port 3 pins that have 1s written to them are pulled high by the internal

pull-ups and can be used as inputs. As inputs, Port 3 pins that are

externally pulled low will source current because of the internal pull-

ups. Port 3 also serves the special features of the 80C51 family, as listed

below.

10

11

5

I

RXD (P3.0): Serial input port

11

13

7

O

TXD (P3.1): Serial output port

12

14

8

I

INT0 (P3.2): External interrupt 0

13

15

9

I

INT1 (P3.3): External interrupt 1

14

16

10

I

T0 (P3.4): Timer 0 external input

15

17

11

I

T1 (P3.5): Timer 1 external input

16

18

12

O

WR (P3.6): External data memory write strobe

17

19

13

O

RD (P3.7): External data memory read strobe

RST

9

10

4

I/O

Reset: A high on this pin for two machine cycles while the oscillator is

an output when the hardware watchdog forces a system reset.

ALE/PROG

30

33

27

O (I)

Address Latch Enable/Program Pulse: Output pulse for latching the

low byte of the address during an access to external memory. In normal

operation, ALE is emitted at a constant rate of 1/6 (1/3 in X2 mode) the

oscillator frequency, and can be used for external timing or clocking.

Note that one ALE pulse is skipped during each access to external data

memory. This pin is also the program pulse input (PROG) during Flash

programming. ALE can be disabled by setting SFR’s AUXR.0 bit. With

this bit set, ALE will be inactive during internal fetches.

PSEN

29

32

26

O

Program Strobe ENable: The read strobe to external program memory.

When executing code from the external program memory, PSEN is

activated twice each machine cycle, except that two PSEN activations

are skipped during each access to external data memory. PSEN is not

activated during fetches from internal program memory.

EA

31

35

29

I

External Access Enable: EA must be externally held low to enable the

device to fetch code from external program memory locations 0000H to

FFFFH (RD). If security level 1 is programmed, EA will be internally

latched on Reset.
