PL102-10

Low Skew Output Buffer

Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1(408) 944 -0800 • fax +1(408) 474-1000 • www.micrel.com Rev 2/5/09 Page 4

SWITCHING WAVE FORMS

All Outputs Rise/Fall Time

0.8V

2.0V

Output

2.0V

0.8V

3.3V

Input to Output Propagation Delay

Input

Output

VDD/2

delay

VDD/2

Device to Device Skew

Device1 CLKOUT

Device2 CLKOUT

VDD/2

dsk - dsk

VDD/2
