LBV330-XXBNDRANX1900 | LBV300

LEVEL SENSORS

Connection diagram

Double relay connection diagram

1

2

3

①  Relay output

②  Relay output

③  Power supply

Instruction for installation

Horizontal mounting

20°

1

2

①  Protective sheet

②  Concave protective sheet for abrasive solids

Recommended accessories

Other models and accessories

www.sick.com/LBV300

Brief description

Type

Part no.

Mounting brackets and mounting plates

Locking screw connection, process pressure –1 bar to 16 bar, process connection G

2 A, inner thread G 1 1/2 A, stainless steel 316L

BEF-MU-316G20-

ALBV

5322462

Electronic modules

Double relay (DPDT): 20 V DC ... 72 V DC / 20 ... 250 V AC

ECD-RE-LB-

VREL-0001

6038666
