Series resistors (R6, R10, R11, R12) can be added to

the gate of MOSFETs (Q1 to Q4) to control the

switching transition times.

This reduces signal

distortion as seen in the THD+N vs. Output Power

graph below.

The slower switching speeds will

however, increase power dissipation and therefore

slightly decrease the overall efficiency of the amplifier.

P+

N+

OUT+

Q1

Q2

R12

10

Ω

R11

10

Ω

- 3451  .  1 $

resistors, which improves (decreases) the THD+N

from 0.1% to 0.05% with a slight impact on efficiency

of approximately 2%. The recommended gate resistor

  1  6!

The oscillator is programmed by the external timing

components RPWM and CPWM.

For a nominal

frequency of 333kHz, RPWM and CPWM should be

set to 49.9kOhms and 100pF respectively. Note that

in order to keep the slope of the PWM ramp voltage

proportional to the supply voltage, both the ramp peak

and valley voltages, and the charge and discharge

currents are proportional to the supply voltage. This

keeps the frequency relatively constant while keeping

the slope of the PWM ramp proportional to the voltage

on the VDD pin. For operating frequencies other than

333kHz, the frequency can be approximated by the

following equation:

ns

C

R

PWM

PWM

320

)

)(

)(

577

.

0

(

1

Frequency

+

=

For applications that require more than a single

channel, the oscillators of

multiple LX1710/1711

controllers

can

be

configured

for

synchronous

operation.

One unit, the master, is programmed for

the desired frequency with the RPWM and CPWM as

usual.

Additional units will be slave units, and their

oscillators will be disabled by leaving the RPWM pin

disconnected. The CLOCK pin and the CPWM pin of

the slave units should be tied to the CLOCK pin and

the CPWM pin of the master unit respectively. In this

configuration, the CLOCK pins of the slave units begin

receiving instead of transmitting clock pulses.

Also,

the CPWM pins quit driving the PWM capacitor in the

slave units.

Note that for optimum performance, all

slave units should be located within a few inches of the

master unit.

Gate Resistor Impact On THD+N

0.001

100

0.005

0.01

0.1

1

2

10

20

50

0.26978

0.04675

50m

30

100m

200m

500m

1

2

5

10

1.131

O utput P ower (W )

N o G ate R esistor

W ith 10

Ω Gate Resistor
