Mitsubishi microcomputers

M16C / 62A Group

SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER

Timing (Vcc = 3V)

193

VCC = 3V

Timing requirements (referenced to VCC = 3V, VSS = 0V at Ta = – 20oC to 85oC / – 40oC to 85oC (*)

unless otherwise specified)

* : Specify a product of -40

°C to 85°C to use it.

Standard

Max.

Min.

Unit

Parameter

Symbol

tw(TAL)

TAiIN input LOW pulse width

tc(TA)

TAiIN input cycle time

150

tw(TAH)

TAiIN input HIGH pulse width

Standard

Max.

Min.

Unit

Parameter

Symbol

tc(TA)

TAiIN input cycle time

600

tw(TAH)

TAiIN input HIGH pulse width

300

tw(TAL)

TAiIN input LOW pulse width

300

Standard

Max.

Min.

Unit

Parameter

Symbol

tc(TA)

TAiIN input cycle time

300

tw(TAH)

TAiIN input HIGH pulse width

150

tw(TAL)

TAiIN input LOW pulse width

150

Standard

Max.

Min.

Unit

Parameter

Symbol

tw(TAH)

TAiIN input HIGH pulse width

150

tw(TAL)

TAiIN input LOW pulse width

150

Standard

Max.

Min.

Unit

Parameter

Symbol

tc(UP)

TAiOUT input cycle time

3000

tw(UPH)

TAiOUT input HIGH pulse width

1500

tw(UPL)

TAiOUT input LOW pulse width

1500

tsu(UP-TIN)

TAiOUT input setup time

600

th(TIN-UP)

TAiOUT input hold time

600

Table 1.23.27. Timer A input (gating input in timer mode)

Table 1.23.28. Timer A input (external trigger input in one-shot timer mode)

Table 1.23.29. Timer A input (external trigger input in pulse width modulation mode)

Table 1.23.30. Timer A input (up/down input in event counter mode)

Table 1.23.26. Timer A input (counter input in event counter mode)
