ADP1653
Rev. B | Page 21 of 24
16
15
14
13
5
6
7
8
12
11
10
9
1
2
3
4
ADP1653
4.7µF
4.7µF
ONE
OR
TWO
LEDs
2.2µH
INPUT VOLTAGE = 2.75V TO 5.5V
VDD
Tx MASK
OPTIONAL
SETT
SETF
CTRL1/SCL
CTRL0/SDA
EN
STR
VDD
LX
SETI ILED
OUT
GND
PGND
INTF
HPLED
INT
Figure 35. Typical Applications Circuit (High Current Lines Are Shown in Bold)
