ADR380/ADR381

Rev. C | Page 14 of 16

OUTLINE DIMENSIONS

3.04

2.90

2.80

COMPLIANT TO JEDEC STANDARDS TO-236-AB

SEATING

PLANE

2.64

2.10

1.40

1.30

1.20

2.05

1.78

0.100

0.013

1.03

0.89

0.60

0.45

0.51

0.37

1.12

0.89

0.180

0.085

0.25

0.54

REF

GAUGE

PLANE

0.60 MAX

0.30 MIN

1.02

0.95

0.88

Figure 31. 3-Lead Small Outline Transistor Package [SOT-23-3]

(RT-3)

Dimensions shown in millimeters

ORDERING GUIDE

Model1

Temperature Range

Package Description

Package

Option

Branding2

Output

Voltage

Ordering

Quantity

ADR380ARTZ-REEL7

−40°C to +85°C

3-Lead SOT-23

RT-3

R2D

2.048

3,000

ADR381ARTZ-R2

−40°C to +85°C

3-Lead SOT-23

RT-3

R3A

2.500

250

ADR381ARTZ-REEL7

−40°C to +85°C

3-Lead SOT-23

RT-3

R3A#

2.500

3,000

1 Z = RoHS Compliant Part, # denotes RoHS compliant product may be top or bottom marked.

2 Prior to Date Code 0542, the ADR380ARTZ-REEL7 parts were branded with R2A without the #.
