Warranty

3 Years

Hardware

Active or Passive Adapter

Active

Audio

Yes

AV Input

USB-C

DisplayPort - 1.2

AV Output

DisplayPort

USB-C

Chipset ID

Chrontel - CH7213C-BF

VIA Labs - VL170

Performance

Audio Specifications

DisplayPort - 7.1 Channel Audio

USB-C - 7.1 Channel Audio

Supported Resolutions

DisplayPort: 3840x2160 (4K) / 60Hz

USB-C: 3840x2160 (4K) / 60Hz

Video Revision

DisplayPort 1.2

Wide Screen Supported

Yes

Connector(s)

Connector A

1 - USB-C (24 pin) DisplayPort Alt Mode Male Input

1 - Thunderbolt™ 3 USB-C (24-pin) (20Gbps) Male Input

Connector B

1 - DisplayPort (20 pin) Male Output

Special Notes /

Requirements

Note

Maximum performance is dependent upon the specifications

of your video source and destination

System and Cable Requirements

Your USB-C device must support DisplayPort Alt Mode to

work with this cable

Environmental

Humidity

10%-85% RH

Operating Temperature

0°C to 45°C (32°F to 113°F)

Storage Temperature

-10°C to 70°C (14°F to 158°F)

Physical

Characteristics

Color

Black

Material

Plastic

Product Height

10.000

Product Length

80.2 in [203.8 cm]

Product Width

220.000

Weight of Product

77.000

Packaging

Information

Package Height

12.000
