LTRB RASF.01
DATASHEET
DATASHEET
5 | Version 1.1 | 2025-02-03
Characteristics
I
F = 20 mA; TS = 25 °C
Parameter
Symbol
Values
Values
Values
● true green
● red
● blue
Peak Wavelength
λ
peak
typ.
525 nm
632 nm
462 nm
Dominant Wavelength 2)
λ
dom
typ.
530 nm
621 nm
465 nm
Spectral bandwidth at 50% I
rel,max
∆λ
typ.
30 nm
18 nm
23 nm
Viewing angle at 50% I
V
2φ
typ.
120 °
120 °
120 °
Forward Voltage 3)
I
F = 20 mA
V
F
min.
typ.
max.
2.10 V
2.75 V
2.90 V
2.10 V
2.40 V
2.70 V
2.70 V
2.80 V
3.30 V
Reverse voltage (ESD device)
V
R ESD
min.
7 V
7 V
7 V
Reverse voltage 1)
I
R = 5 mA
V
R
max.
10 V
10 V
10 V
Real thermal resistance junction/sol-
derpoint 4)
R
thJS real
typ.
550 K / W
560 K / W
390 K / W
