AD8615/AD8616/AD8618

Rev. C | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

Differential Input Voltage

±3 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature

–65°C to +150°C

Operating Temperature Range

–40°C to +125°C

Lead Temperature Range (Soldering 60 sec)

300°C

Junction Temperature

150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only and functional operation of the device at these or

any other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

specified for device soldered in circuit board for surface-mount

packages.

Table 4.

Package Type

Unit

5–Lead TSOT-23 (UJ)

207

61

°C/W

8-Lead MSOP (RM)

210

45

°C/W

8-Lead SOIC (R)

158

43

°C/W

14-Lead SOIC (R)

120

36

°C/W

14-Lead TSSOP (RU)

180

35

°C/W

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
