Preliminary Technical Data
SSM2602
Rev. PrB | Page 5 of 28
TIMING CHARACTERISTICS
Table 4.
Limit
Parameter
tMIN
tMAX
Unit
Description
fSCLK
0
550
kHz
SCLK frequency
tSCLKPL
1.3
μs
SCLK low pulse width
tSCLKPH
600
ns
SCLK high pulse width
tSCH
600
ns
Hold time (start condition)
tSCS
600
ns
Setup time (start condition)
tDS
100
ns
Data setup time
tSDIN-SCLKR
300
ns
SDIN, SCLK rise time
tSDIN-SCLKF
300
ns
SDIN, SCLK fall time
tHCS
600
ns
Setup time (hold condition)
tDH
900
ns
Data hold time
TIMING DIAGRAMS
TBD
