AD8045ACPZ-R2 Datasheet(PDF) 21 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
AD8045ACPZ-R2 Datasheet(HTML) 21 Page - Analog Devices |
|
|
21 / 24 page  Data Sheet AD8045 Rev. C | Page 21 of 24 CH1 M4.00ns A CH1 0.00V 1 50.0mV Figure 71. Small Signal Transient Response of 90 MHz LPF CH1 M4.00ns A CH1 0.00V 1 500mV Figure 72. Large Signal Transient Response of 90 MHz LPF U1 C1 7.1pF C2 7.1pF R1 249 Ω RT 49.9 Ω R2 249 Ω R3 499 Ω R5 249 Ω R4 499 Ω C5 5pF R9 24.9 Ω RT 49.9 Ω INPUT –5V +5V 0.1 µF 0.1 µF 10 µF 10 µF U1 C3 7.1pF C4 7.1pF R6 249 Ω R8 499 Ω R7 499 Ω –5V +5V 0.1 µF 0.1 µF 10 µF 10 µF OUTPUT Figure 73. 4-Pole, 90 MHz, Sallen-Key Low-Pass Filter |
|
|
