Click here for the 3D model.

Dimensions



L

20.6mm +/-1mm

T

16.8mm +/-1mm

H

24.5mm +/-1mm

S

13mm +/-0.5mm

S1

10mm +/-0.5mm

Wire Size

0.5mm

Packaging Specifications



Packaging

Tray

Packaging Quantity

480

Typical Component Weight

11.9 g

General Information



Series

SS21VB

Style

Through-Hole

RoHS

Yes

Miscellaneous

Temperature Rise Maximum: 30 K.

Core

Mn-Zn Ferrite

Specifications



Voltage AC

500 VAC

Inductance

1.3 mH

Current

2 A

Temperature Range

-40/+120°C

DC Resistance

0.096 Ohms

SS21VB-R200013

Aliases (UAL21VBR200013)

KEMET, SS21VB, AC Line Filters, Common Mode, 1.3 mH
