13 / 226 page ![]() 2017-2018 Microchip Technology Inc. DS00002419D-page 13 KSZ9563R Port 3 Receive Data Valid / Carrier Sense / Control RX_DV/ CRS_DV/ RX_CTL IPD/O24 MII Mode: RX_DV is the Port 3 Received Data Valid output. RMII Mode: CRS_DV is the Carrier Sense / Receive Data Valid output. RGMII Mode: RX_CTL is the Receive Control output. Note: This pin also provides configuration strap func- tions during hardware/software resets. Refer to Section 3.2.1, "Configuration Straps" for addi- tional information. Port 3 Receive Error RX_ER IPD/O24 MII Mode: Port 3 Receive Error output. RMII/RGMII Modes: Not used. Do not connect this pin in these modes of operation. Note: This pin also provides configuration strap func- tions during hardware/software resets. Refer to Section 3.2.1, "Configuration Straps" for addi- tional information. Port 3 Receive Data 3 RXD3 IPD/O24 MII/RGMII Modes: Port 3 Receive Data bus bit 3. RMII Mode: Not used. Do not connect this pin in this mode of operation. Note: This pin also provides configuration strap func- tions during hardware/software resets. Refer to Section 3.2.1, "Configuration Straps" for addi- tional information. Port 3 Receive Data 2 RXD2 IPD/O24 MII/RGMII Modes: Port 3 Receive Data bus bit 2. RMII Mode: Not used. Do not connect this pin in this mode of operation. Note: This pin also provides configuration strap func- tions during hardware/software resets. Refer to Section 3.2.1, "Configuration Straps" for addi- tional information. Port 3 Receive Data 1 RXD1 IPD/O24 MII/RMII/RGMII Modes: Port 3 Receive Data bus bit 1. Note: This pin also provides configuration strap func- tions during hardware/software resets. Refer to Section 3.2.1, "Configuration Straps" for addi- tional information. Port 3 Receive Data 0 RXD0 IPD/O24 MII/RMII/RGMII Modes: Port 3 Receive Data bus bit 0. Note: This pin also provides configuration strap func- tions during hardware/software resets. Refer to Section 3.2.1, "Configuration Straps" for addi- tional information. TABLE 3-2: PIN DESCRIPTIONS (CONTINUED) Name Symbol Buffer Type Description |
|
