125L Series

www.vishay.com

Vishay Cera-Mite

Revision: 23-Jul-2021

3

Document Number: 23106

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

Notes

• Marking IEC 60384-14 does not apply for Ø

 9 mm

• “XX - XXX” is a placeholder for date code and lot number:



“XX -” is the year and month according to IEC 60062



“- XXX” is the last 3 digits of the lot number

APPROVALS

IEC 60384-14 - Safety tests



This approval together with CB test certificate substitutes all national approvals.

Y4-capacitor: CB test certificate:

DE1-63495

1 nF to 50 nF

X1-capacitor: CB test certificate:

DE1-63495

1 nF to 50 nF

Y4-capacitor: VDE marks approval:

40003976

1 nF to 50 nF

X1-capacitor: VDE marks approval:

40003976

1 nF to 50 nF

DIN EN 60384-14 VDE 0565-1-1 - Safety tests

Y4-capacitor: UL test certificate:

E99264

1 nF to 50 nF

X1-capacitor: UL test certificate:

E99264

1 nF to 50 nF

UL 60384-14, CSA E60384-1, CSA E60384-14

Fixed capacitors for electromagnetic interference suppression and connection to the supply mains.

MARKING

Sample

IEC 60384-14

125L

472M

CM

XX - XXX

Y4 125V~

X1 400V~
