TEMPERATURE SPECIFICATIONS (Note 1)

Parameters

Symbol

Min.

Typ.

Max.

Units

Conditions

Temperature Ranges+85

Ambient Operating Temperature (TA)

—

+70

°C

Commercial

–40

+85

Industrial

Junction Temperature

—

+150

°C

—

Storage Temperature Range

–65

—

+150

°C

—

Package Thermal Resistance

8-Lead SOIC

RθJA

—

103.2

—

°C/W —

Note 1: The maximum allowable power dissipation is a function of ambient temperature, the maximum allowable

junction temperature and the thermal resistance from junction to air (i.e., TA, TJ, JA). Exceeding the

maximum allowable power dissipation will cause the device operating junction temperature to exceed the

maximum +150°C rating. Sustained junction temperatures above +150°C can impact the device reliability.
