Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

20190423

(1/4)

beads_automotive_power_mpz2012_en.fm

EMC Components

Chip beads

For power line

MPZ series (for automotive)

MPZ2012 type

FEATURES

Noise reduction solution for power line.

Compared to the MMZ series, has low direct current resistance for compatibility with large currents, optimal for low power consumption.

Performs well even in signal lines where low direct current resistance is required.

Operating temperature range: –55 to +125°C

Compliant with AEC-Q200

APPLICATION

Various ECUs, powertrains, body controls, and car multimedia (telematics).

PART NUMBER CONSTRUCTION

CHARACTERISTICS SPECIFICATION TABLE

Measurement equipment

＊ Equivalent measurement equipment may be used.

Rated current vs. temperature characteristics (derating)

MPZ

2012

S

101

A

T

D25

Series name

L×W×T dimensions

Material name

Impedance

Characteristic

type

Packaging style

Internal code

2.0×1.25x0.85 mm

(

) at 100MHz

Impedance

DC resistance

Part No.

[100MHz]

(

)

Tolerance

(

)max.

(A)max.

30

±10



0.010

6

MPZ2012S300ATD25

100

±25%

0.020

4

MPZ2012S101ATD25

220

±25%

0.040

3

MPZ2012S221ATD25

330

±25%

0.050

2.5

MPZ2012S331ATD25

600

±25%

0.100

2

MPZ2012S601ATD25

1000

±25%

0.150

1.5

MPZ2012S102ATD25

Measurement item

Product No.

Manufacturer

Impedance

E4991A+16192A

Keysight Technologies

DC resistance

Type-7556

Yokogawa

AEC-Q200

S300A

S331A

S101A

S221A

S601A

S102A

0

1

2

3

4

5

6

7

–55 –35

–15

5

25

45

65

85

105

125

Temperature (°C)

REACH

SVHC-Free

Lead

Free

RoHS

Pb

Halogen

Free

Br

Cl
