FP1008L1-R150-R Datasheet(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP1008L1-R150-R Datasheet(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 6 page  Technical Data 10450 Effective December 2015 Supersedes October 2015 FP1008L High frequency, high current power inductors Description • High current carrying capacity • Low DCR • Low core loss • Controlled DCR for sensing circuits • Inductance range from 100nH to 150nH • Current range from 50 to 75 amps • 9.6 x 6.4 and 7.5mm footprint surface mount package in an 8.0mm height • Ferrite core material • Halogen free, lead free, RoHS compliant Applications • Servers • Multi-phase and Vcore regulators • Voltage Regulator Modules (VRMs) • Server and desktop • Central processing unit (CPU) • Graphics processing unit (GPU) • Application specific integrated circuit (ASIC) • High power density • Data networking and storage systems • Graphics cards and battery power systems • Point-of-Load modules • DCR Sensing circuits Environmental Data • Storage temperature range (Component): -40°C to +125°C • Operating temperature range: -40°C to +125°C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020D compliant Pb HALOGEN HF FREE |
