MODEL SWTW

BI Technologies Corporation

4200 Bonita Place, Fullerton, CA 92835 USA

August 9, 2010

page 2 of 6

BI technologies

6 x 6 mm (G, X, J, and H styles only)

6 x 6 mm (S style only)

1

Contact our customer service for custom designs and features.

SWTW - G 1 S TR

Model Series

Style

G – Top Actuation SMD – G Pin,

6 x 6 mm

X – Top Actuation SMD – G pin

with Ground, 6 x 6 mm

Available in Stem Height “2” &

Color “N” only

J – Top Actuation, SMD J pin

H –Top Actuation, Through hole

Stem Height (Colors Available)

1 – 2.3mm, available in Silver (S) only

2 – 3.1mm, available in Brown (N) only

3 – 3.5mm, available in N, R, T

4 – 3.8mm, available in N, R, T

5 – 4.5mm, available in N, R

6 – 5.2mm, available in N, R, T

Packaging

Blank – 75 pcs,/tube, Style H only

TR – Tape and Reel

Style G & X

Stem Height 1 & 2 – 2000 pcs

Stem Height 3 & 4 – 1900 pcs

Stem Height 5 & 6 – 900 pcs

Style J

Stem Height 1 – 2700 pcs

Stem Height 2 – 1900 pcs

Stem Height 3 & 4 – 1800 pcs

Stem Height 5 & 6 – 900 pcs

Color / Force

N – Brown, 160 gf for Stem 2, 180 gf for others

S – Silver, 160 gf

R – Red, 260 gf

T – Transparent, 360 gf

SWTW - S 1 W B B TR

Model Series

Style

S – Side Actuation,

SMD J pin style

Stem Height: (H)

1 – 2.8mm

2 – 4.35mm

3 – 2.3mm

4 – 4.0mm

Packaging

TR – Tape and Reel

Without Pick & Place tab – 600 pcs

With Pick & Place tab – 550 pcs

Stem Color / Force

W - White, 185 gf

R - Red, 260 gf

V - White, 260 gf

X – Red, 185 gf

Front Solder Pad

A – Without pad

(Option, Consult Factory)

B – With pad

Pick & Place Tab

A – Without tab

B – With tab
