HCMA0503-R20-R Datasheet(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
HCMA0503-R20-R Datasheet(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 7 page  Technical Data 10248 Effective June 2016 Supersedes June 2015 HCMA0503 Automotive grade High current power inductors Description • AEC-Q200 Grade 3 qualified • High current carrying capacity • Low core losses • Magnetically shielded, low EMI • Frequency range up to 1 MHz • Inductance range from 0.2 μH to 22 μH • Current range from 1.9 A to 22 A • 5.5 mm x 5.3 mm footprint surface mount pack- age in a 3.0 mm height • Iron powder core material • Halogen free, lead free, RoHS compliant Applications • Body electronics • Central body control module • Vehicle access control system • Headlamps, tail lamps and interior lighting • Heating ventilation and air conditioning con- trollers (HVAC) • Doors, window lift and seat control • Advanced driver assistance systems • 77 GHz radar systems • Basic and smart surround, and rear and front view camera • Adaptive cruise control (ACC) • Automatic parking control • Collision avoidance system • Car black box system • Infotainment and cluster electronics • Active noise cancellation (ANC) • Audio subsystem: head unit and trunk amp - Digital instrument cluster • In-vehicle infotainment (IVI) and navigation • Chassis and safety electronics • Airbag control unit Environmental Data • Storage temperature range (Component): -55 °C to +125 °C • Operating temperature range: -55 °C to +125 °C (ambient + self-temperature rise) • Solder reflow temperature: J-STD-020D compliant Pb HALOGEN HF FREE |
