Technical Data DS4313

Effective June 2017

FP1308

High frequency, high current power inductors

www.eaton.com/electronics

1

2

FP1308-XXX

wwllyy R

12.95 max.

13.70 max.

8.0 max.

5.4

2.54 (2plcs)

8.0

7.62

3.18

7.2

1

2

Top View

Bottom View

Recommended Pad Layout

Front View

Left View

Schematic

D

Diim

me

en

ns

siio

on

ns

s -- m

mm

m

2.0

1.5 diia. min

A

1.75

Section A-A

11.5

24.0 ±0.3

13.9

FP1308-XXX

wwllyy R

13.2

A

User direction of feed

4.0

1.5 dia. +0.1/-0.0

8.2

0

20

40

60

80

100

Total Loss (W)

3

2.5

2

1.5

1

0.5

0

Part Marking: FP1308

xxx = Inductance value in

μH. (R = Decimal point). If no “R” is present, then last character is # 0f zeros

wwllyy = Date code

R = Revision level

Supplied in tape-and-reel packaging, 400 parts per reel, 13” diameter reel.

Packaging Information - mm

Temperature Rise vs. Total Loss
