Revision History

REV.A1

99.12.21

Page 145 Note 2

• Before data can be written to the SI/Oi transmit/receive register (addresses

036016, 036416), the CLKi pin input must be in the low state. Also, before rewriting

the SI/Oi Control Register (addresses 036216, 036616)’s bit 7 (SOUTi initial value

set bit), make sure the CLKi pin input is held low. ---> • Before data can be written

to the SI/Oi transmit/receive register (addresses 036016, 036416), the CLKi pin

input must be in the high state. Also, before rewriting the SI/Oi Control Register

(addresses 036216, 036616)’s bit 7 (SOUTi initial value set bit), make sure the CLKi

pin input is held high.

00.7.3

REV. A2

Page 43, Figure 1.10.6

Note: Writing a value to an address after “1” is written to this bit returns the bit to

“0” . Other bits do not automatically return to “0” and they must therefore

be reset by the program.

Page 144, Figure 1.16.32, bit 5 of the SI/Oi control register (i=3, 4)

Transfer direction lect bit --->Transfer direction select bit

Page 144, Figure 1.16.32, Note 2

When using the port as an input/output port by setting the SI/Oi port select bit (i =

3, 4) to “1”, be sure to set the sync clock select bit to “1”.

--->

When using the port as an input/output port by setting the SI/Oi port select bit (i =

3, 4) to “0”, be sure to set the sync clock select bit to “1”.

00.7.10

Page 115, 139, Bit 3 of the UART2 special mode register 2 (bit symbol)

ASL --> ALS
