MODE

OSPI_PHY_CONFIGURATION_REG BIT

FIELD

DELAY VALUE

3.3V

PHY_CONFIG_TX_DLL_DELAY_FLD

0x2F

Receive

1.8V, Internal PHY Loopback

PHY_CONFIG_RX_DLL_DELAY_FLD

0x40

3.3V, Internal PHY Loopback

PHY_CONFIG_RX_DLL_DELAY_FLD

0x32

1.8V, External Board Loopback

PHY_CONFIG_RX_DLL_DELAY_FLD

0x0

3.3V, External Board Loopback

PHY_CONFIG_RX_DLL_DELAY_FLD

0x0

6.11.5.13.2.3.1.2 OSPI1 Timing Requirements - PHY SDR Mode

NO.

PARAMETER

DESCRIPTION

MODE

MIN

MAX

UNIT

O19

tsu(D-CLK)

Setup time, OSPI_D[7:0] valid

before active OSPI_CLK edge

1.8V, SDR with

Internal PHY

Loopback

3.3V, SDR with

Internal PHY

Loopback

O20

th(CLK-D)

Hold time, OSPI_D[7:0] valid after

active OSPI_CLK edge

1.8V, SDR with

Internal PHY

Loopback

0.25

3.3V, SDR with

Internal PHY

Loopback

O21

tsu(D-LBCLK)

Setup time, OSPI_D[7:0] valid

before active OSPI_DQS edge

1.8V, SDR with

External Board

Loopback

3.3V, SDR with

External Board

Loopback

O22

th(LBCLK-D)

Hold time, OSPI_D[7:0] valid after

active OSPI_DQS edge

1.8V, SDR with

External Board

Loopback

3.3V, SDR with

External Board

Loopback

tO20t

O19

OSPI_CLK

OSPI_D[i:0]

Figure 6-56. OSPI Timing Requirements – PHY SDR with Internal PHY Loopback

tO22t

O21

OSPI_DQS

OSPI_D[i:0]

Figure 6-57. OSPI Timing Requirements – PHY SDR with External Board Loopback

www.ti.com

AM2612, AM2611, AM2611-Q1, AM2612-Q1

SPRSPA7C – SEPTEMBER 2024 – REVISED JULY 2025

Submit Document Feedback

161

Product Folder Links: AM2612 AM2611 AM2611-Q1 AM2612-Q1
