203 / 218 page  www.ti.com C 1.3 MAX 0.33 0.23 TYP 12.35 TYP 12.35 TYP 0.65 TYP 0.65 TYP 304X 0.45 0.35 A 13.35 13.15 B 13.35 13.15 (0.45) TYP (0.45) TYP NFBGA - 1.3 mm max height ZFG0304A PLASTIC BALL GRID ARRAY 4230188/A 11/2023 NOTES: 1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing per ASME Y14.5M. 2. This drawing is subject to change without notice. BALL A1 CORNER SEATING PLANE 0.1 C 0.15 CA B 0.05 C PKG PKG BALL A1 CORNER Y 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 20 19 W V U T R P N M L K J H G F E D C B A SCALE 0.900 www.ti.com AM2612, AM2611, AM2611-Q1, AM2612-Q1 SPRSPA7C – SEPTEMBER 2024 – REVISED JULY 2025 Copyright © 2025 Texas Instruments Incorporated Submit Document Feedback 203 Product Folder Links: AM2612 AM2611 AM2611-Q1 AM2612-Q1 |
|
